50 piece (MOQ)
| Business Type | Manufacturer, Supplier |
| Material | HAVELLS COMBO |
| Shape | Rectangle |
| Application | solar panel us |
| Click to view more | |
Product Details
ACDB & DCDB – Solar Protection and Distribution Boxes The ACDB (AC Distribution Box) and DCDB (DC Distribution Box) are important protection and distribution components used in solar power systems. Designed for solar installations in the 1–6 kW range, these boxes provide a convenient and organized arrangement of protection devices for the AC and DC sides of a solar PV system. The products shown are assembled with Havells protection components and are supplied through an authorised dealer of Havells. DCDB – DC Distribution Box The DCDB is installed on the DC side of a solar power system, between the solar PV panels and the solar inverter. Electricity generated by the solar panels is in DC form, and the DCDB provides a dedicated enclosure for controlling and protecting this section of the installation. The DCDB shown in the image includes Havells DC protection devices, including a 2-pole MCB and surge protection devices (SPD). The MCB provides switching and overcurrent protection for the DC circuit, while the SPD helps protect the connected solar equipment against voltage surges and transient overvoltage conditions. A properly installed DCDB helps keep the wiring and protective devices arranged in a compact and accessible enclosure. It also makes isolation and maintenance of the DC side more convenient for qualified technicians. The enclosure helps protect the internal components from accidental contact and provides a cleaner, safer installation compared with leaving individual protection devices exposed. The DCDB is particularly useful in rooftop solar systems, residential solar plants, small commercial installations, and other PV applications where dedicated DC-side protection and isolation are required. ACDB – AC Distribution Box The ACDB is installed on the AC side of the solar inverter. After the inverter converts the DC electricity generated by the solar panels into AC electricity, the ACDB provides a dedicated location for AC-side protection and distribution before the power is connected to the electrical system. The ACDB shown features Havells AC protection components, including an AC MCB and surge protection devices. The MCB provides circuit protection and a means of isolation, while the SPD is intended to help protect the AC-side organized inside a dedicated enclosure. This makes the system easier to inspect and maintain while providing a professional appearance for equipment and electrical installation from transient voltage surges. The ACDB keeps the AC protection arrangement organized inside a dedicated enclosure. This makes the system easier to inspect and maintain while providing a professional appearance for residential, commercial, and solar installation projects. Key Features Suitable for solar PV systems in the 1–6 kW range. Separate ACDB and DCDB configurations for AC- and DC-side protection. Fitted with Havells MCB and SPD components as shown. Compact enclosure for neat and organized installation. Provides convenient isolation and circuit protection. Surge protection helps reduce the risk associated with transient voltage surges. Suitable for residential and small commercial solar installations. Designed to keep important protection components enclosed and properly arranged. Easy access for inspection and maintenance by qualified electrical professionals. Helps provide a cleaner and more professional solar electrical installation. The pictured units carry a “Danger – Electrical Hazard” warning for safety awareness. Why ACDB and DCDB Are Important in Solar Systems A solar power system contains both DC and AC electrical circuits, and each side requires protection appropriate to its electrical characteristics. The DCDB protects and isolates the DC circuit between the solar panels and inverter, while the ACDB provides protection and isolation on the AC side of the inverter. Using dedicated distribution boxes helps organize the protection
